OLED0802A Character LCD Module
The OLED0802A Character LCD Module (XNYOLED0802A) is a reliable and versatile character display solution suitable for a wide range of applications. This compact module offers clear and concise text information display, making it ideal for integration into various electronic devices and embedded systems.
Key Benefits:
- Clear and concise character display
- Compact and easy to integrate (58×32×10mm outline dimension)
- Durable and reliable performance (backed by a 3-year warranty)
- Cost-effective character display solution
- Customizable to meet specific interface or application requirements
- Stable signal transmission with WS0010 controller and parallel port interface
Target Industries and Applications:
This 8×2 character OLED LCD module features self-luminous OLED display technology, ensuring high contrast ratio and crisp text readability under all ambient light conditions. Equipped with a parallel port interface and integrated WS0010 driver IC, it supports stable signal transmission and consistent performance. With its compact structure and wide operating temperature adaptability, it delivers reliable long-term working performance in diverse environments, suitable for:
- Industrial control panels
- Smart instruments and meters
- Consumer electronics
- Embedded system displays
- Portable electronic devices
- Smart home devices
| Attribute |
Value |
FOB Price |
FOB Unit |
| Black Color |
Black-White |
$80 |
Piece |
| Black Color |
Black-Blue |
$83 |
Piece |
| Black Color |
Black-Yellow |
$81 |
Piece |
| Black Color |
Black-Green |
$82 |
Piece |
| Black Color |
Black-Red |
$85 |
Piece |
Technical Specifications
| Attribute |
Value |
| Display Mode |
OLED0802A |
| Hign-concerned Chemical |
None |
| Resolution |
8*2 |
| is_customized |
Yes |
| Model Number |
OLED0802A |
| Type |
OLED |
| Origin |
Mainland China |
| Outline Dimension |
58×32×10mm |
| View Size |
38×16mm |
| Controller |
WS0010 |
